Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply

Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply

    • Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply
    • Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply
    • Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply
    • Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply
  • Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply

    उत्पाद विवरण:

    Place of Origin: China
    ब्रांड नाम: LABWE multi-Touch Interactive Whiteboard,low cost classroom white board
    प्रमाणन: ISO 9001, CE, FCC, ISO14001 (environment certificate), RoHS
    Model Number: LWB-5401
    Sample policy:: sample is available for multi-Touch Interactive Whiteboard,low cost classroom white board

    भुगतान & नौवहन नियमों:

    Minimum Order Quantity: 1 Piece/Pieces
    Packaging Details: CARTONS ( wooden can be available if in special amount and requirement)
    Delivery Time: 7 days after payment
    Payment Terms: T/T
    Supply Ability: 300 PCS/DAY
    अब से संपर्क करें
    विस्तृत उत्पाद विवरण
    Cursor blink rate: 120 Dots/Second HDD: 1GB free space
    Memory: 256MB RAM PC Interface: USB2.0
    Operating: touch, writing, mark, interactive, smart
    हाई लाइट:

    touch screen Interactive Whiteboard

    ,

    education Interactive Whiteboard



    Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply



    Model:LWB-5401

    Physical Size: 54 inches

    Effective Size: 47.4 inches

    Phase Ratio: 4:3

    Effective Response Area: 1006mm X 680mm, Effective Writing Area: 978mm X 652mm

    Physical Dimensions: 946mm X 1271mm X 82mm

    Shortcuts: Right

    Net Weight: 8 kg

    Gross Weight: 13 kg



    multi-Touch Interactive Whiteboard,low cost classroom white board Specification



    multi-Touch Interactive Whiteboard,low cost classroom white board Harware Features



    1) Whiteboard material: Imported PET material, matt surface

    2) Screen surface: The hard-coated steel surface is durable, optimized for projection, compatible with dry-erase markers and easily cleaned with whiteboard cleaner. Green, Environmentally friendly.

    3) PCB finish: All the electronic parts are finished by SMT, therefore, the PCB looks clean and tidy and functions stably.

    4) Wall-mount bracket: Four M8 screws and toggle bolt anchors (two upper/ lower frame, adjustable) to support a wall-mounted interactive whiteboard.

    5) Portable stand: Available for different sized interactive whiteboard

    6) Computer connection: 16' (5 m) USB 2.0 cable, Plug and play, no need to install driver or server to run the whiteboard.

    7) Power requirements : Power consumption is less than 7 W (USB 5V voltage, current < 100mA).

    8) Plug and Play, no need to install driver



    multi-Touch Interactive Whiteboard,low cost classroom white board Software Features

    1) Touch and gesture: Perform mouse functions with your finger: to write, click and right click. Recognize guestures: fist gesture to earase, two fingers(one hand) touch to move and two fingers (two hands) touch to zoom in and out of images.
    2) Resolution: Touch resolution is 8192 × 8192
    3) Smooth writing, without any breakpoint or sharp curve
    4) Compatible with Win, Mac OS, Linux and Android
    5) Interaction functions: To use any type of computer and projector to make up interactive e-educational environment
    6) Short cuts on both sides of the whiteboard, convenient to operate.
    7) PPT import and editable.
    8) Save Interactive whiteboard data as Doc., Picture, PDF, HTML, PPT, etc.
    9) Whiteboard data can be printed
    10) For modes(Teaching mode, Annotation mode, Design mode, Control Mode) satisfy different needs.
    11) Insert function: Insert Table, Function, Image, Video, Audio, Flash, Text, Link, Lines, Shapes, etc.
    12) Multi-tools: Different kinds of tools to choose from including Pens, Erasers, Sportlight, Curtain, Clock, Keyboard, Camera, Video/Audio recorder, Magnify, etc.
    13) Math tools: Including Calculator, Ruler, Compasses, Set square, Protractor, etc.
    14) External tool: Allow you to add any EXE. File to the whiteboard to achieve interactive environment.
    15) Resource library: Abount teaching resources, you can also add by yourself, convenient for teaching.

    Technical Specifications for multi-Touch Interactive Whiteboard,low cost classroom white board

    Touch Features
     Operating Principle: Infrared Induction Technology
     Positioning Accuracy: <2mm
     Cursor Blink Rate: 120 Dots/Second
     Resolution: 8192 × 8192
     Response Time: < 8ms in continuous writing practice
     I nduction Size: > 3.0mm, Recommended Size:> 5.0mm (Diameter)
     T ouch Spot Life Span: Over 60,000,000 times single spot touch

    Working Environment

     Power Supply: USB power supply (No external power supply needed)
     Operating Voltage: DC 4.6V ~ DC 5V
     Power Consumption: <1W, USB 5V voltage, current < 100mA
     CPU: X86-based processor, pentium III or above;
     Memory: 256MB RAM (512MB RAM recommended);
     HDD: 1GB free space;
     USB: At least a spare USB interface;
     Projection Equipment: Normal projector compatible.
     Operating Temperature: -10 °C to 45 °C
     Operating Humidity: 20% to 85%
     Light Test: Incandescent (220V, 100W), working distance: 350mm
     Altitude: 3,000 meters or below
     PC Interface: USB2.0
     Working Life: 5 years or above
     Work Environment: Under daylight, indoor & outdoor environment.

    Packing List

    Standard Accessories
     LABWE (Infrared) Electronic Blackboard: 1
     Normal ink pen markable: 3
     USB cable (5 Meters, Blue): 1
     Installation Software Disk: 1
     User's Manual: 1
     Service Card: 1
     Wall-mounting Parts: 1
     Screws (ST4 * 30mm KA): 8
     Plastic Gecko (6 * 29mm): 8

    Optional Accessories

     Mobile Stand: 1set
     USB Extension HUB Cable (5 Meters, Silver): 1 piece

    Application:

    Labwe multi-Touch Interactive Whiteboard,low cost classroom white board adopts Infrared Technology, finger touch sensitive. Widely used for schools, whiteboard classroom , conference, military and many other occasions.



    Advantages:

    Plug and Play

    SMT Technology

    CE/FCC/ROHS certified

    Multi languages

    Available on Windows/Linux/Mac/Android system

    Professional Technical Support

    3 years warranty

    Easy maintenance

    Factory price

    40 minutes to Shenzhen port, fast delivry





    Packing & Shipping for multi-Touch Interactive Whiteboard,low cost classroom white board



    Samples usually packed in cartons with wooden cases, for bulk quantities, goods usually shipping by sea with containers.



    Our services



    Samples are accepted, and will be deliveried within 7 working days. OEM/ODM services are welcomed. We offer online support 24/7, 3 years waranty for all our products.


    Function:

    usb support,finger writing,infrared,mounted on wall,portable,mobile,moveable,short throw projector,usb port,all in one,anti-scratch,markable,multi point touch, gestures recognition,32 point,64 point,10 point,dual writing ,IR,wall hang,easy taking


    Description:

    smart active board for Schools

    LABWE (Infrared) interactive whiteboard , is a large interactive display that connects to a computer. A projector projects the computer's desktop onto the board's surface where users control the computer using a pen, finger, stylus, or other device. The board is typically mounted to a wall or floor stand.
    They are used in a variety of settings, including classrooms at all levels of education, in corporate board rooms and work groups, in training rooms for professional sports coaching, in broadcasting studios, and others.


    smart active board adopts Infrared Technology, finger touch sensitive.



    Certification: ISO 9001, CE, FCC, ISO14001 (environment certificate), RoHS
